Dell OptiPlex Gn - Figure 1-4. Internal View of the Midsize Computer

1-6
Dell OptiPlex Gn and Gn+ Systems Service Manual
Figure 1-4. Internal View of the Midsize Computer
parallel port connector
power supply
voltage
selection switch
AC power
receptacle
serial port 1 connector
drive cage
diskette/tape drive interface cable
hard-disk drive
bracket
hard-disk drive
interface cable
3.5-inch diskette drive
expansion-card cage
expansion-card slots (5)
video connector
padlock ring
security cable slot
system board
optional system board
NIC connector (Gn+)
USB connectors (2)
keyboard connector
mouse connector
serial port 2 connector
