System Overview 1-5
Figure 1-3. Internal View of the Low-Profile Computer
CAUTION: To avoid possible data or file structure corruptions, the
front-panel reset button should be used only when the computer cannot
be rebooted by pressing
<
Ctrl
><
Alt
><
Del
>
. Before you use the reset
button to initiate a hardware reset, close any open application programs
and files if possible.
serial port 1
connector
power supply
voltage
selection
switch
AC power
receptacle
3.5-inch diskette drive
expansion-card
cage
USB connectors (2)
keyboard connector
video connector
expansion-card slots (3)
hard-disk drive
optional system board
NIC connector (Gn+)
hard-disk drive
interface cable
diskette/tape drive
interface cable
parallel port
connector
mouse connector
serial port 2 connector
padlock ring
security cable slot
system board
