Figure 5-8 shows an example of drive hardware that can be installed in the com-
puter. Refer to this figure when you perform any of the procedures in the
following subsections.
Figure 5-8. Drive Hardware
diskette/tape drive
interface cable
DC power cable
DSKT connector
system
power supply
hard-disk drive bracket
secondary EIDE connector (IDE2)
primary EIDE
connector (IDE1)
EIDE cable
3.5-inch diskette drive
