Dell OptiPlex Gn - Drives; Figure 6-8. Drive Hardware

Removing and Replacing Parts on the Mini Tower Chassis 6-9
D
rives
Figure 6-8 shows an example of drive hardware that can be installed in the com-
puter. Refer to this figure when you perform any of the procedures in the
following subsections.
Figure 6-8. Drive Hardware
diskette/tape drive
interface cable
DC power cable
DSKT connector
hard-disk drive bracket
primary EIDE
connector (IDE1)
secondary EIDE
connector (IDE2)
EIDE cable
3.5-inch diskette drive
