Configuring Switching Information 455
Figure 7-120. States of Client Binding
To access the DHCP Snooping Static Bindings Configuration page, click Switching
→
DHCP
Snooping
→
Static Bindings Configuration in the navigation tree.
Figure 7-121. DHCP Snooping Static Bindings Configuration
The DHCP Snooping Static Bindings Configuration page contains the following fields:
•
Interface
— Select the interface to add a binding into the DHCP snooping database.
•
MAC Address
— Specify the MAC address for the binding to be added. This is the Key to the binding
database.
•
VLAN ID
— Select the VLAN from the list for the binding rule. The range of the VLAN ID is 1 to
4093.
No Binding
Tentative
Binding
Complete
Binding
RELEASE, NACK
DISCOVER
ACK
DISCOVER,
REQUEST
DECLINE,
NACK
To Next Page
