Table 28. Port n (continued)
Options Descriptions
Capacity Specifies the total capacity of the drive. This field is undefined
for removable media devices such as optical drives.
NVMe Settings
This option sets the NVMe drive mode. If the system contains NVMe drives that you want to configure in a RAID array, you
must set both this field and the Embedded SATA field on the SATA settings menu to RAID Mode. You may also need to change
the Boot Mode setting to UEFI.
To view the NVMe Settings screen, power on the system, press F2, and click System Setup Main Menu > System BIOS >
NVMe Settings.
Table 29. NVMe Settings details
Option Description
NVMe mode Enables or disables the boot mode. The option is set to Non-RAID mode by default.
BIOS NVMe Driver Sets the drive type to boot the NVMe driver. The available options are Dell Qualified
Drives and All Drives. This option is set to Dell Qualified Drives by default.
Boot Settings
You can use the Boot Settings screen to set the boot mode to either BIOS or UEFI. It also enables you to specify the boot
order. The Boot Settings only support UEFI mode.
● UEFI: The Unified Extensible Firmware Interface (UEFI) is a new interface between operating systems and platform
firmware. The interface consists of data tables with platform related information, boot and runtime service calls that are
available to the operating system and its loader. The following benefits are available when the Boot Mode is set to UEFI:
○ Support for drive partitions larger than 2 TB.
○ Enhanced security (e.g., UEFI Secure Boot).
○ Faster boot time.
NOTE: You must use only the UEFI boot mode in order to boot from NVMe drives.
● BIOS: The BIOS Boot Mode is the legacy boot mode. It is maintained for backward compatibility.
To view the Boot Settings screen, power on the system, press F2, and click System Setup Main Menu > System BIOS >
Boot Settings.
Table 30. Boot Settings details
Option Description
Boot Mode Enables you to set the boot mode of the system. If the operating system supports
UEFI, you can set this option to UEFI. Setting this field to BIOS allows compatibility
with non-UEFI operating systems. This option is set to UEFI by default.
CAUTION: Switching the boot mode may prevent the system from
booting if the operating system is not installed in the same boot mode.
NOTE: Setting this field to UEFI disables the BIOS Boot Settings menu.
Boot Sequence Retry Enables or disables the Boot sequence retry feature or resets the system. When
this option is set to Enabled and the system fails to boot, the system re-attempts
the boot sequence after 30 seconds. When this option is set to Reset and the
system fails to boot, the system reboots immediately. This option is set to Enabled
by default.
Hard-disk Failover Enables or disables the Hard-disk failover. This option is set to Disabled by default.
Generic USB Boot Enables or disables the generic USB boot placeholder. This option is set to
Disabled by default.
Pre-operating system management applications 39
