Figure 98. Installing GPU air shroud
9 Press the blue tabs on either sides of the shroud and remove the top cover of the shroud.
Figure 99. Removing the top cover of the shroud
10 If applicable, remove the shroud ller from the GPU air shroud slots.
NOTE
: Shroud llers are available in the GPU air shroud for GPUs installed on riser 2 and
3.
148 Installing and removing system components
