Dell PowerEdge R740xd - Installing the Optional Front Bezel

Figure 17. Removing the optional front bezel with the LCD panel
Installing the optional front bezel
The procedure to install the optional front bezel with the LCD panel and the front bezel without the LCD panel is the same.
Prerequisite
Follow the safety guidelines listed in Safety instructions.
Steps
1 Locate and remove the bezel key.
NOTE
: The bezel key is part of the LCD bezel package.
2 Align and insert the right end of the bezel onto the system.
3 Press the release button and t the left end of the bezel onto the system.
4 Lock the bezel by using the key.
Installing and removing system components
67
