Dell PowerEdge R740xd - Removing NVDIMM-N Battery from the Bracket

Figure 36. Installing NVDIMM-N battery into mid drive tray
Next step
Follow the procedure listed in After working inside your system.
Removing NVDIMM-N battery from the bracket
Prerequisites
1 Follow the safety guidelines listed in Safety instructions.
2 Follow the procedure listed in Before working inside your system.
CAUTION
: NVDIMM-N battery is not hot swappable. To prevent data loss and potential damage to your system, ensure
that your system, LEDs on system, LEDs on NVDIMM-N and LEDs on NVDIMM-N battery are turned o before
removing the NVDIMM-N battery.
CAUTION: To avoid damage to the battery connector, you must rmly support the connector while installing or
removing a battery.
Step
Press the release tab and slide out the NVDIMM-N battery to disengage the tab on the battery from the slot on the bracket.
86
Installing and removing system components
