Figure 46. Installing a 2.5 inch drive into the 3.5 inch mid drive carrier
Next step
Follow the procedure listed in After working inside your system.
Drives
Drives are supplied in hot swappable drive carriers that t in the drive slots.
CAUTION
: Before attempting to remove or install a drive while the system is running, see the documentation for the storage
controller card to ensure that the host adapter is congured correctly.
CAUTION: Do not turn o or restart your system while a drive is being formatted. Doing so can cause a drive
failure.
When you format a drive, allow enough time for the formatting to complete. Be aware that high-capacity drives can take a long time to
format.
Removing a drive blank
The procedure for removing 2.5 inch and 3.5 inch drive blanks is identical.
Prerequisites
1 Follow the safety guidelines listed in Safety instructions.
2 If installed, remove the front bezel.
Installing and removing system components
97
