Virtual Extensible LAN (VXLAN)

Virtual Extensible LAN (VXLAN) is supported on Dell Networking OS.

Overview

The switch acts as the VXLAN gateway and performs the VXLAN Tunnel End Point (VTEP) functionality. VXLAN is a technology where in

the data trac from the virtualized servers is transparently transported over an existing legacy network.

Figure 150. VXLAN Gateway

Topics:

• Components of VXLAN network

• Functional Overview of VXLAN Gateway

• VXLAN Frame Format

• Conguring and Controlling VXLAN from the NVP Controller GUI

• Conguring VxLAN Gateway

• Displaying VXLAN Congurations

• VXLAN Service nodes for BFD

• Static Virtual Extensible LAN (VXLAN)

• Preserving 802.1 p value across VXLAN tunnels

Virtual Extensible LAN (VXLAN) 1053
