If you delete the dot1p priority-priority group mapping (no priority pgid command) before you apply the new DCB map, the
default PFC and ETS parameters are applied on the interfaces. This change may create a DCB mismatch with peer DCB devices and
interrupt network operation.
Data Center Bridging: Default Conguration
Before you congure PFC and ETS on a switch see the priority group setting taken into account the following default settings:
DCB is enabled.
PFC and ETS are globally enabled by default.
The default dot1p priority-queue assignments are applied as follows:
Dell(conf)#do show qos dot1p-queue-mapping
Dot1p Priority : 0 1 2 3 4 5 6 7
Queue : 0 0 0 1 2 3 3 3
Dell(conf)#
PFC is not applied on specic dot1p priorities.
ETS: Equal bandwidth is assigned to each port queue and each dot1p priority in a priority group.
To congure PFC and ETS parameters on an interface, you must specify the PFC mode, the ETS bandwidth allocation for a priority group,
and the 802.1p priority-to-priority group mapping in a DCB map. No default PFC and ETS settings are applied to Ethernet interfaces.
Conguring Priority-Based Flow Control
Priority-Based Flow Control (PFC) provides a ow control mechanism based on the 802.1p priorities in converged Ethernet trac received
on an interface and is enabled by default when you enable DCB.
As an enhancement to the existing Ethernet pause mechanism, PFC stops trac transmission for specied priorities (Class of Service
(CoS) values) without impacting other priority classes. Dierent trac types are assigned to dierent priority classes.
When trac congestion occurs, PFC sends a pause frame to a peer device with the CoS priority values of the trac that is to be stopped.
Data Center Bridging Exchange protocol (DCBx) provides the link-level exchange of PFC parameters between peer devices. PFC allows
network administrators to create zero-loss links for Storage Area Network (SAN) trac that requires no-drop service, while retaining
packet-drop congestion management for Local Area Network (LAN) trac.
To congure PFC, follow these steps:
1 Create a DCB Map.
CONFIGURATION mode
dcb-map dcb-map-name
The dcb-map-name variable can have a maximum of 32 characters.
2 Create a PFC group.
CONFIGURATION mode
priority-group group-num {bandwidth bandwidth | strict-priority} pfc on
The range for priority group is from 0 to 7.
Set the bandwidth in percentage. The percentage range is from 1 to 100% in units of 1%.
Committed and peak bandwidth is in megabits per second. The range is from 0 to 40000.
Committed and peak burst size is in kilobytes. Default is 50. The range is from 0 to 10000.
