Splitting 40G Ports without Reload
You can split 40G interfaces into 10G ports without reboot. You can also combine the split ports to create a 40G port without reload.
• The switch consists of six 40G ports (49,50,51,52,53,54) that can be split into 10G ports.
• In stacking, congure prole rst before provisioning for new units. Otherwise it is mandatory to reload for prole to take eect.
• If there is a mismatch in fan-out prole between master and the new member in stacking, the master re-congures the member with
its quad-mode prole, quad-mode, and stack-group conguration and then reset the member. To avoid stack split during prole
mismatch, the master does stack group congurations of the new member.
To congure the quad-port-prole, use the following command:
CONFIGURATION mode
stack-unit stack-unit number port port-number portmode quad
The defaults ports are:
49,50,51,52,53,54
To display the Fan-out capability prole, use the following show command:
show system stack-unit stack-unit number fanout configured
Example of the
show Command
The following example shows the show system stack-unit stack-unit number fanout
configured command.
Dell#show system stack-unit 1 fanout configured
Configured fan out ports in stack-unit 1
Configured Present
49 49
50 50
51 51
52 52
53 53
54 54
The following example shows the interface status before splitting a 40G interface:
Dell#show interfaces status
Port Description Status Speed Duplex Vlan
Fo 1/49 Down 40000 Mbit Auto --
Fo 1/50 Down 40000 Mbit Auto --
The following example shows splitting a 40G interface:
Dell(conf)#stack-unit 1 port 49 portmode quad
Warning: Enabling Quad mode on stack-unit 1 port 49. Please verify whether the configs related
to interface Fo 1/49 are cleaned up before proceeding further.
[confirm yes/no]:yes
Quad mode is enabled on stack-unit 1 port 49
Dell(conf)#Jan 1 13:37:01: %STKUNIT1-M:CP %IFMGR-5-DYNAMIC_FANOUT: Port 49 in slot 1 has been
fanned-out
TenGigabitEthernet 1/49/1 unassigned NO Manual administratively down down
TenGigabitEthernet 1/49/2 unassigned NO Manual administratively down down
TenGigabitEthernet 1/49/3 unassigned NO Manual administratively down down
TenGigabitEthernet 1/49/4 unassigned NO Manual administratively down down
The following example shows the split interfaces:
Dell#show interfaces status
Port Description Status Speed Duplex Vlan
Te 1/49/1 Down 10000 Mbit Auto --
