Dell S4048-ON - Configuring Transmit and Receive Mode; Configuring the Time to Live Value

R1(conf-lldp)#show config
!
protocol lldp
advertise dot1-tlv port-protocol-vlan-id port-vlan-id
advertise dot3-tlv max-frame-size
advertise management-tlv system-capabilities system-description
no disable
R1(conf-lldp)#
Conguring Transmit and Receive Mode
After you enable LLDP, the system transmits and receives LLDPDUs by default.
To congure the system to transmit or receive only and return to the default, use the following commands.
• Transmit only.
CONFIGURATION mode or INTERFACE mode
mode tx
• Receive only.
CONFIGURATION mode or INTERFACE mode
mode rx
• Return to the default setting.
CONFIGURATION mode or INTERFACE mode
no mode
Example of Conguring a Single Mode
R1(conf)#protocol lldp
R1(conf-lldp)#show config
!
protocol lldp
advertise dot1-tlv port-protocol-vlan-id port-vlan-id
advertise dot3-tlv max-frame-size
advertise management-tlv system-capabilities system-description
no disable
R1(conf-lldp)#mode ?
rx Rx only
tx Tx only
R1(conf-lldp)#
mode tx
R1(conf-lldp)#show config
!
protocol lldp
advertise dot1-tlv port-protocol-vlan-id port-vlan-id
advertise dot3-tlv max-frame-size
advertise management-tlv system-capabilities system-description
mode tx
no disable
R1(conf-lldp)#
no mode
R1(conf-lldp)#show config
!
protocol lldp
advertise dot1-tlv port-protocol-vlan-id port-vlan-id
advertise dot3-tlv max-frame-size
advertise management-tlv system-capabilities system-description
no disable
R1(conf-lldp)#
Conguring the Time to Live Value
The information received from a neighbor expires after a specic amount of time (measured in seconds) called a time to live (TTL).
The TTL is the product of the LLDPDU transmit interval (hello) and an integer called a multiplier. The default multiplier is 4, which results in
a default TTL of 120 seconds.
