Figure 48. Membership Queries: Leaving and Staying

Congure IGMP

Conguring IGMP is a two-step process.

1 Enable multicast routing using the ip multicast-routing command.

2 Enable a multicast routing protocol.

Related Conguration Tasks

• Viewing IGMP Enabled Interfaces

• Selecting an IGMP Version

• Viewing IGMP Groups

• Adjusting Timers

• Preventing a Host from Joining a Group

• Enabling IGMP Immediate-Leave

• IGMP Snooping

• Fast Convergence after MSTP Topology Changes

• Designating a Multicast Router Interface
