Dell S4048-ON - Enabling the Fcoe Transit Feature

• You can congure multiple FCF-trusted interfaces in a VLAN.
• When you disable FIP snooping:
• ACLs are not installed, FIP and FCoE trac is not blocked, and FIP packets are not processed.
• The existing per-VLAN and FIP snooping conguration is stored. The conguration is re-applied the next time you enable the FIP
snooping feature.
• You must apply the CAM-ACL space for the FCoE region before enabling the FIP-Snooping feature. If you do not apply CAM-ACL
space, the following error message is displayed:
Dell(conf)#feature fip-snooping
% Error: Cannot enable fip snooping. CAM Region not allocated for Fcoe.
Dell(conf)#
NOTE: Manually add the CAM-ACL space to the FCoE region as it is not applied by default.
To support FIP-Snooping and set CAM-ACL, usecam-acl l2acl 4 ipv4acl 4 ipv6acl 0 ipv4qos 2 l2qos 1 l2pt 0
ipmacacl 0 vman-qos 0 ecfmacl 0 fcoeacl 2 command.
CAM ACL Table
-- Chassis Cam ACL --
Current Settings(in block sizes)
1 block = 128 entries
L2Acl : 4
Ipv4Acl : 4
Ipv6Acl : 0
Ipv4Qos : 2
L2Qos : 1
L2PT : 0
IpMacAcl : 0
VmanQos : 0
VmanDualQos : 0
EcfmAcl : 0
FcoeAcl : 2
iscsiOptAcl : 0
ipv4pbr : 0
vrfv4Acl : 0
Openflow : 0
fedgovacl : 0
nlbclusteracl: 0
st-sjc-s5000-29#
Enabling the FCoE Transit Feature
The following sections describe how to enable FCoE transit.
NOTE
: FCoE transit is disabled by default. To enable this feature, you must follow the Congure FIP
Snooping.
As soon as you enable the FCoE transit feature on a switch-bridge, existing VLAN-specic and FIP snooping congurations are applied.
The FCoE database is populated when the switch connects to a converged network adapter (CNA) or FCF port and compatible DCB
congurations are synchronized. By default, all FCoE and FIP frames are dropped unless specically permitted by existing FIP snooping-
generated ACLs. You can recongure any of the FIP snooping settings.
If you disable FCoE transit, FIP and FCoE trac are handled as normal Ethernet frames and no FIP snooping ACLs are generated. The
VLAN-specic and FIP snooping conguration is disabled and stored until you re-enable FCoE transit and the congurations are re-applied.
FIP Snooping
327
