12 View the UDF TCAM conguration.
CONFIGURATION-UDF TCAM mode
show config
Dell(config-ext-nacl)#show config
!
ip access-list extended aa
seq 5 permit ip any any udf-pkt-format ipnip udf-qualifier-value ipnip_val1
Dell(config-ext-nacl)#
Conguring IP Mirror Access Group
To congure an IP mirror access group on an interface, use the following commands:
1 Allocate CAM prole for IPv4 ACL.
CONFIGURATION mode
cam-acl {default | l2acl number ipv4acl number ipv6acl number ipv4qos number l2qos number
l2pt number ipmacacl number [vman-qos | vman-qos—dual— number | vman-qos—dual—fp number]
ipv4pbr number} ecfmacl number [nlbclusteraclnumber]fcoeacl number iscsioptacl number
ipv4udfmirracl number}
2 Create a monitor session.
CONFIGURATION mode
monitor session session-ID [type { rpm | erpm [set ip dscp dscp_value | set ip ttl
ttl_value]}] [drop]
Dell(conf)#monitor session 65535 type erpm
3 Create an IP access-list.
CONFIGURATION mode
ip access-list {standard | extended} access-list-name
Dell(conf)#ip access-list standard test
4 Congure a lter to permit the IP packets.
CONFIGURATION—STANDARD—ACCESS—LIST mode
CONFIGURATION—EXTENDED—ACCESS—LIST mode
permit {source mask | any | host ip-address} {destination mask | any | host ip-address}
[count [bytes]] [dscp value] [order] [fragments] [monitor [session-id]] [no-drop]
Dell(config-ext-nacl)#permit ip any any count monitor 65535
5 Associate the IP access list to an interface.
INTERFACE mode
ip mirror-access-group access-list-name {in | out} [implicit-permit] [vlan vlan-id]
[optimized]
Dell(conf-if-te-0/4)#ip mirror-access-group acl3 in
To view which IP mirror-access-group is applied to an interface, use the show config command in INTERFACE mode, or use the show
running-config command in EXEC mode.
