Dell S4048-ON - Configure Static Routes for the Management Interface

• tag tag-value: the range is from 1 to 4294967295. (optional)
Example of the show ip route static Command
To view the congured routes, use the show ip route static command.
Dell#show ip route static
Destination Gateway Dist/Metric Last Change
----------- ------- ----------- -----------
S 2.1.2.0/24 Direct, Nu 0 0/0 00:02:30
S 6.1.2.0/24 via 6.1.20.2, Te 5/1 1/0 00:02:30
S 6.1.2.2/32 via 6.1.20.2, Te 5/1 1/0 00:02:30
S 6.1.2.3/32 via 6.1.20.2, Te 5/1 1/0 00:02:30
S 6.1.2.4/32 via 6.1.20.2, Te 5/1 1/0 00:02:30
S 6.1.2.5/32 via 6.1.20.2, Te 5/1 1/0 00:02:30
S 6.1.2.6/32 via 6.1.20.2, Te 5/1 1/0 00:02:30
S 6.1.2.7/32 via 6.1.20.2, Te 5/1 1/0 00:02:30
S 6.1.2.8/32 via 6.1.20.2, Te 5/1 1/0 00:02:30
S 6.1.2.9/32 via 6.1.20.2, Te 5/1 1/0 00:02:30
S 6.1.2.10/32 via 6.1.20.2, Te 5/1 1/0 00:02:30
S 6.1.2.11/32 via 6.1.20.2, Te 5/1 1/0 00:02:30
S 6.1.2.12/32 via 6.1.20.2, Te 5/1 1/0 00:02:30
S 6.1.2.13/32 via 6.1.20.2, Te 5/1 1/0 00:02:30
S 6.1.2.14/32 via 6.1.20.2, Te 5/1 1/0 00:02:30
S 6.1.2.15/32 via 6.1.20.2, Te 5/1 1/0 00:02:30
S 6.1.2.16/32 via 6.1.20.2, Te 5/1 1/0 00:02:30
S 6.1.2.17/32 via 6.1.20.2, Te 5/1 1/0 00:02:30
S 11.1.1.0/24 Direct, Nu 0 0/0 00:02:30
Direct, Lo 0
--More--
Dell Networking OS installs a next hop that is on the directly connected subnet of current IP address on the interface.
Dell Networking OS also installs a next hop that is not on the directly connected subnet but which recursively resolves to a next hop on the
interface's congured subnet.
• When the interface goes down, Dell Networking OS withdraws the route.
• When the interface comes up, Dell Networking OS re-installs the route.
• When the recursive resolution is “broken,” Dell Networking OS withdraws the route.
• When the recursive resolution is satised, Dell Networking OS re-installs the route.
Congure Static Routes for the Management
Interface
When an IP address that a protocol uses and a static management route exists for the same prex, the protocol route takes precedence
over the static management route.
To congure a static route for the management port, use the following command.
• Assign a static route to point to the management interface or forwarding router.
CONFIGURATION mode
management route ip-address mask {forwarding-router-address | ManagementEthernet slot/port}
Example of the show ip management-route Command
To view the congured static routes for the management port, use the show ip management-route command in EXEC privilege
mode.
Dell#show ip management-route
Destination Gateway State Route Source
----------- ------- ----- ------------
10.16.0.0/16 ManagementEthernet 1/1 Connected Connected
172.16.1.0/24 10.16.151.4 Active Static
IPv4 Routing
437
