Dell S4048-ON - Configuring Lossless Queues

The pfc on command enables priority-based ow control.
3 Specify the dot1p priority-to-priority group mapping for each priority.
priority-pgid dot1p0_group_num dot1p1_group_num ...dot1p7_group_num
Priority group range is from 0 to 7. All priorities that map to the same queue must be in the same priority group.
Leave a space between each priority group number. For example: priority-pgid 0 0 0 1 2 4 4 4 in which priority group 0 maps to dot1p
priorities 0, 1, and 2; priority group 1 maps to dot1p priority 3; priority group 2 maps to dot1p priority 4; priority group 4 maps to dot1p
priorities 5, 6, and 7.
Dell Networking OS Behavior: As soon as you apply a DCB policy with PFC enabled on an interface, DCBx starts exchanging information
with PFC-enabled peers. The IEEE802.1Qbb, CEE, and CIN versions of PFC Type, Length, Value (TLV) are supported. DCBx also validates
PFC congurations that are received in TLVs from peer devices.
NOTE: You cannot enable PFC and link-level ow control at the same time on an
interface.
Conguring Lossless Queues
DCB also supports the manual conguration of lossless queues on an interface when PFC mode is turned o.
Prerequisite: A DCB with PFC conguration is applied to the interface with the following conditions:
• PFC mode is o (no pfc mode on).
• No PFC priority classes are congured (no pfc priority priority-range).
Example:
Port A —> Port B
Port C —> Port B
PFC no-drop queues are congured for queues 1, 2 on Port B. PFC capability is enabled on priorities 3, 4 on PORT A and C.
Port B acting as Egress
During the congestion, [trac pump on priorities 3 and 4 from PORT A and PORT C is at full line rate], PORT A and C send out the PFCs
to rate the trac limit. Egress drops are not observed on Port B since trac ow on priorities is mapped to loss less queues.
Port B acting as Ingress
If the trac congestion is on PORT B , Egress DROP is on PORT A or C, as the PFC is not enabled on PORT B.
Refer the following conguration for queue to dot1p mapping:
NOTE
: Although, each port on the S4810, S4820T, and S5000 devices support 8 QoS queues, you can congure only 4 QoS
queues (0-3) to manage data trac. The remaining 4 queues (4-7) are reserved for control trac.
Dell(conf)#do show qos dot1p-queue-mapping
Dot1p Priority : 0 1 2 3 4 5 6 7
Queue : 0 0 0 1 2 3 3 3
Dell(conf)#
The conguration of no-drop queues provides exibility for ports on which PFC is not needed but lossless trac should egress from the
interface.
Lossless trac egresses out the no-drop queues. Ingress dot1p trac from PFC-enabled interfaces is automatically mapped to the no-drop
egress queues.
1 Enter INTERFACE Conguration mode.
CONFIGURATION mode
Data Center Bridging (DCB)
259
