Dell S4048-ON - Configuring a Static Route; Sample VRF Configuration

Conguring a Static Route
• Congure a static route that points to a management interface.
CONFIGURATION
management route ip-address mask managementethernet ormanagement route ipv6-address prefix-
length managementethernet
You can also have the management route to point to a front-end port in case of the management VRF. For example: management
route 2::/64 tengigabitethernet 1/1.
• Congure a static entry in the IPv6 neighbor discovery.
CONFIGURATION
ipv6 neighbor vrf management 1::1 tengigabitethernet 1/1 xx:xx:xx:xx:xx:xx
Sample VRF Conguration
The following conguration illustrates a typical VRF set-up.
Figure 157. Setup OSPF and Static Routes
1072
Virtual Routing and Forwarding (VRF)
