show frrp summary
Ring ID: the range is from 1 to 255.
Troubleshooting FRRP
To troubleshoot FRRP, use the following information.
Conguration Checks
• Each Control Ring must use a unique VLAN ID.
• Only two interfaces on a switch can be Members of the same control VLAN.
• There can be only one Master node for any FRRP group.
• You can congure FRRP on Layer 2 interfaces only.
• Spanning Tree (if you enable it globally) must be disabled on both Primary and Secondary interfaces when you enable FRRP.
• When the interface ceases to be a part of any FRRP process, if you enable Spanning Tree globally, also enable it explicitly for the
interface.
• The maximum number of rings allowed on a chassis is 255.
Sample Conguration and Topology
The following example shows a basic FRRP topology.
Example of R1 MASTER
interface TenGigabitEthernet 1/24
no ip address
switchport
no shutdown
!
interface TenGigabitEthernet 1/34
no ip address
switchport
no shutdown
!
interface Vlan 101
no ip address
tagged TenGigabitEthernet 1/24,34
no shutdown
!
interface Vlan 201
no ip address
tagged TenGigabitEthernet 1/24,34
no shutdown
!
protocol frrp 101
interface primary TenGigabitEthernet 1/24
secondary TenGigabitEthernet 1/34 control-vlan 101
member-vlan 201
mode master
no disable
Example of R2 TRANSIT
interface TenGigabitEthernet 2/14
no ip address
switchport
no shutdown
!
interface TenGigabitEthernet 2/31
no ip address
switchport
