Access Control Lists (ACLs)
This chapter describes access control lists (ACLs), prex lists, and route-maps.
At their simplest, access control lists (ACLs), prex lists, and route-maps permit or deny trac based on MAC and/or IP addresses. This
chapter describes implementing IP ACLs, IP prex lists and route-maps. For MAC ACLS, refer to Layer 2.
An ACL is essentially a lter containing some criteria to match (examine IP, transmission control protocol [TCP], or user datagram protocol
[UDP] packets) and an action to take (permit or deny). ACLs are processed in sequence so that if a packet does not match the criterion in
the rst lter, the second lter (if congured) is applied. When a packet matches a lter, the switch drops or forwards the packet based on
the lter’s specied action. If the packet does not match any of the lters in the ACL, the packet is dropped (implicit deny).
The number of ACLs supported on a system depends on your content addressable memory (CAM) size. For more information, refer to User
Congurable CAM Allocation and CAM Optimization. For complete CAM proling information, refer to Content Addressable Memory
(CAM).
You can congure ACLs on VRF instances. In addition to the existing qualifying parameters, Layer 3 ACLs also incorporate VRF ID as one of
the parameters. Using this new capability, you can also congure VRF based ACLs on interfaces.
NOTE
: You can apply Layer 3 VRF-aware ACLs only at the ingress level.
You can apply VRF-aware ACLs on:
• VRF Instances
• Interfaces
In order to congure VRF-aware ACLs on VRF instances, you must carve out a separate CAM region. You can use the cam-acl command
for allocating CAM regions. As part of the enhancements to support VRF-aware ACLs, the cam-acl command now includes the following
new parameter that enables you to allocate a CAM region:
vrfv4acl.
The order of priority for conguring user-dened ACL CAM regions is as follows:
• V4 ACL CAM
• VRF V4 ACL CAM
• L2 ACL CAM
With the inclusion of VRF based ACLs, the order of precedence of Layer 3 ACL rules is as follows:
• Port/VLAN based PERMIT/DENY Rules
• Port/VLAN based IMPLICIT DENY Rules
• VRF based PERMIT/DENY Rules
• VRF based IMPLICIT DENY Rules
NOTE
: In order for the VRF ACLs to take eect, ACLs congured in the Layer 3 CAM region must have an implicit-permit
option.
You can use the ip access-group command to congure VRF-aware ACLs on interfaces. Using the ip access-group command, in
addition to a range of VLANs, you can also specify a range of VRFs as input for conguring ACLs on interfaces. The VRF range is from 1 to
63. These ACLs use the existing V4 ACL CAM region to populate the entries in the hardware and do not require you to carve out a separate
CAM region.
NOTE
: You can congure VRF-aware ACLs on interfaces either using a range of VLANs or a range of VRFs but not both.
