ip address 2.0.0.2/24
tagged TenGigabitEthernet 3/1
no shutdown
!
interface Vlan 256
ip vrf forwarding green
ip address 3.0.0.2/24
tagged TenGigabitEthernet 3/1
no shutdown
!
router ospf 1 vrf blue
router-id 1.0.0.2
network 11.0.0.0/24 area 0
network 1.0.0.0/24 area 0
passive-interface TenGigabitEthernet 2/1
!
router ospf 2 vrf orange
router-id 2.0.0.2
network 21.0.0.0/24 area 0
network 2.0.0.0/24 area 0
passive-interface TenGigabitEthernet 2/2
!
ip route vrf green30.0.0.0/24 3.0.0.1
!
The following shows the output of the show commands on Router 1.
Router 1
Dell#show ip vrf
VRF-Name VRF-ID Interfaces
default-vrf 0 Te 3/1-3/3,
Te 1/3-1/47,
Te 2/1-2/47,
Ma 1/1,
Ma 2/1,
Nu 0,
Vl 1
blue 1 Te 1/1,
Vl 128
orange 2 Te 1/2,
Vl 192
green 3 Te 1/3,
Vl 256
Dell#show ip ospf 1 neighbor
Neighbor ID Pri State Dead Time Address Interface Area
1.0.0.2 1 FULL/DR 00:00:32 1.0.0.2 Vl 128 0
Dell#sh ip ospf 2 neighbor
Neighbor ID Pri State Dead Time Address Interface Area
2.0.0.2 1 FULL/DR 00:00:37 2.0.0.2 Vl 192 0
Dell#show ip route vrf blue
Codes: C - connected, S - static, R - RIP,
B - BGP, IN - internal BGP, EX - external BGP,LO - Locally Originated,
O - OSPF, IA - OSPF inter area, N1 - OSPF NSSA external type 1,
N2 - OSPF NSSA external type 2, E1 - OSPF external type 1,
E2 - OSPF external type 2, i - IS-IS, L1 - IS-IS level-1,
L2 - IS-IS level-2, IA - IS-IS inter area, * - candidate default,
> - non-active route, + - summary route
Gateway of last resort is not set
Destination Gateway Dist/Metric Last Change
----------- ------- ----------- -----------
C 1.0.0.0/24 Direct, Vl 128 0/0 00:20:48
C 10.0.0.0/24 Direct, Te 1/1 0/0 00:10:06
O 11.0.0.0/24 via 1.0.0.2, Vl 128 110/2 00:11:13
