Figure 31. PFC and ETS Applied to LAN, IPC, and SAN Priority Trac

QoS Trac Classication: The service-class dynamic dot1p command has been used in Global Conguration mode to map

ingress dot1p frames to the queues shown in the following table. For more information, refer to

QoS dot1p Trac Classication and Queue

Assignment.

The following describes the dot1p-priority class group assignment

dot1p Value in

the Incoming

Frame

Priority Group Assignment

0 LAN

1 LAN

2 LAN

3 SAN

4 IPC

Data Center Bridging (DCB) 291
