• number is the number in sequence to initiate this rule
• ip-address is the Forwarding router’s address
• tunnel is used to congure the tunnel settings
• tunnel-id is used to redirect the trac
• track <obj-id> is used to track the object-id
• track is to enable the tracking
• FORMAT: A.B.C.D
• FORMAT: slot/port[/subport]
• ip-protocol-number or protocol-type is the type of protocol to be redirected
• FORMAT: 0-255 for IP protocol number, or enter protocol type
• source ip-address or any or host ip-address is the Source’s IP address
• FORMAT: A.B.C.D/NN, or ANY or HOST IP address
• destination ip-address or any or host ip-address is the Destination’s IP address
• FORMAT: A.B.C.D/NN, or ANY or HOST IP address
To delete a rule, use the no redirect command.
The redirect rule supports Non-contiguous bitmasks for PBR in the Destination router IP address
The following example shows how to create a rule for a redirect list by conguring:
• IP address of the next-hop router in the forwarding route
• IP protocol number
• Source address with mask information
• Destination address with mask information
Example: Creating a Rule
Dell(conf-redirect-list)#redirect ?
A.B.C.D Forwarding router's address
Dell(conf-redirect-list)#redirect 3.3.3.3 ?
<0-255> An IP protocol number
icmp Internet Control Message Protocol
ip Any Internet Protocol
tcp Transmission Control Protocol
udp User Datagram Protocol
Dell(conf-redirect-list)#redirect 3.3.3.3 ip ?
A.B.C.D Source address
any Any source host
host A single source host
Dell(conf-redirect-list)#redirect 3.3.3.3 ip 222.1.1.1 ?
Mask A.B.C.D or /nn Mask in dotted decimal or in slash format
Dell(conf-redirect-list)#redirect 3.3.3.3 ip 222.1.1.1 /32 ?
A.B.C.D Destination address
any Any destination host
host A single destination host
Dell(conf-redirect-list)#redirect 3.3.3.3 ip 222.1.1.1 /32 77.1.1.1 ?
Mask A.B.C.D or /nn Mask in dotted decimal or in slash format
Dell(conf-redirect-list)#redirect 3.3.3.3 ip 222.1.1.1 /32 77.1.1.1 /32 ?
Dell(conf-redirect-list)#redirect 3.3.3.3 ip 222.1.1.1 /32 77.1.1.1 /32
Dell(conf-redirect-list)#do show ip redirect-list
IP redirect-list xyz:
Defined as:
seq 5 redirect 3.3.3.3 ip host 222.1.1.1 host 77.1.1.1
Applied interfaces:
None
674
Policy-based Routing (PBR)
