Dell S4048-ON - Page 777

To Next Page

To Previous Page

interface TenGigabitEthernet 3/2

ip address 10.11.20.1/24

no shutdown

interface TenGigabitEthernet 3/4

ip address 192.168.1.1/24

no shutdown

interface TenGigabitEthernet 3/5

ip address 192.168.2.1/24

no shutdown

router rip

version 2

network 10.11.20.0

network 10.11.30.0

network 192.168.1.0

network 192.168.2.0

Routing Information Protocol (RIP) 777
