Field (OID) Description

SNMPv2-SMI::enterprises.6027.3.11.1.3.1.1.3 Optics Type

SNMPv2-SMI::enterprises.6027.3.11.1.3.1.1.4 Vendor Name

SNMPv2-SMI::enterprises.6027.3.11.1.3.1.1.5 Part Number

SNMPv2-SMI::enterprises.6027.3.11.1.3.1.1.6 Serial Number

SNMPv2-SMI::enterprises.6027.3.11.1.3.1.1.7 Transmit Power

SNMPv2-SMI::enterprises.6027.3.11.1.3.1.1.8 Receive Power
