Example of Viewing STP Guard Conguration

Dell#show spanning-tree 0 guard

Interface

Name Instance Sts Guard type

--------- -------- --------- ----------

Te 1/1 0 INCON(Root) Rootguard

Te 1/2 0 LIS Loopguard

Te 1/3 0 EDS (Shut) Bpduguard

936 Spanning Tree Protocol (STP)
