Dell#

00:13:06: %STKUNIT0-M:CP %SYS-5-CONFIG_I: Configured from console by console

Dell# show running-config uplink-state-group

uplink-state-group 3

description Testing UFD feature

downstream disable links 2

downstream TenGigabitEthernet 1/1-2,5,9,11-12

upstream TenGigabitEthernet 1/3-4

Dell#

show uplink-state-group 3

Uplink State Group: 3 Status: Enabled, Up

Dell# show uplink-state-group detail

(Up): Interface up (Dwn): Interface down (Dis): Interface disabled

Uplink State Group : 3 Status: Enabled, Up

Upstream Interfaces : Te 1/3(Up) Te 1/4(Dwn)

Downstream Interfaces : Te 1/1(Dis) Te 1/2(Dwn) Te 1/5(Dwn) Te 1/9(Dwn) Te 1/11(Dwn)

Te 1/12(Dwn)

Uplink Failure Detection (UFD) 967
