6.2.1.2. Manual Mode
1. Navigate to and highlight Manual Mode.
2. Press to display the Manual Mode screen.
3. Manual Mode allows you to set the setpoint (SP), and the High Limit set
point (HLSP).
a. Press or to navigate through the menu.
b. Select and highlight the menu item.
c. Press .
d. Press or to change values.
e. Press to select the value.
4. Manual Mode allows you to set event relay status
a. Press or to navigate to and select the appropriate relay
(Figure 13).
b. Press to toggle the relay on and off.
5. Once all parameters are set, press or to navigate to and highlight
Start.
6. Press to start the process.
a. Press to abort the process.
b. After pressing , press to return to Select a Mode screen
7. Adjust the temperature setpoint while running in Manual or Timer Mode
by:
a. Press .
b. Press or to select mode of operation.
c. Press .
d. Press or to change the SP value.
e. Press .
f. Press to return to normal display.
8. Return to Stopped Mode at any time, press and the Cycle Complete LED
will illuminate Press to select a mode screen.
