DS-320SA
Instruction Manual - 32 -
www.doallsaws.com
pic: 9-8
Name Description/Settings
Par. 7:
Cutting travel delay
(s)
Setting of the delay of the arm motion to the cut. The arm waits for the time
set and only then starts moving to the cut.
Par. 8:
User DPP position
(in)
User setting of the top arm position. This is active only if the arm height
measuring function is active. The position reached by the arm when moving
up after finishing the cut is thereby set.
Par. 9:
User down limit
position (in)
User setting of the bottom arm position. This is active only if the arm height
measuring function is active. The position at which the arm finishes the cut
is there by set.
pic: 9-9
Name Description/Settings
Par. 10:
Arm speed
movement mode
0 – speed moving OFF
1 – speed moving is ON only above the upper possition
2 – speed moving ON no matter where
