DS-320SA
Instruction Manual - 9 -
www.doallsaws.com
3.3 INFORMATION ON DRIVE
type
rated
output
Pn [hp]
rated
voltage
Un [V]
rated
current
In [A]
Turns
[*min-1]
performance
[l/min]
Indukta –
3SIEK90L4A
3,5 230 9,6 1745 -
Varvel: SRT08528G635, i=28
UL
0,17 230 0,5
- -
MAAL71-14F85-4A 0,75 230 2,6 1680 -
tab: 3-6
3.4 THE AMOUNT OF SERVICE/OPERATING FLUIDS
*The amount of hydraulic oil is only for your orientation – the minimum level of oil is determined by the
transparent oil level indicator.
*The amount of emulsion oil is only for your orientation. To check the sufficient amount of the coolant – it is
the task of operators of the majority of machines. The level of coolant is from 30 to 60 mm below the level
of the flange of coolant pump.
There is a longlife syntetic oil filled in the gearboxes: it is not necessary to make any service or filling the oil
during average 15.000 hours of lifetime.
tab: 3-7
3.5 EMISSIONS – MACHINE NOISE LEVEL
In regard to emissions, the machine operators are in no danger of taking in harmful gaseous products during
the operation of the machine.
The machine noise level specifies a method for measuring the emission sound pressure levels of machinery
and equipment at a work station and at other specified positions nearby in a semi-reverberant field. Noise is
measured in units of sound pressure called decibels (dB).
The noise level at a workplace of a machine (the emission sound pressure level) has to be mentioned and
specified in the user manual if it exceeds 70 dB(A).
Table 1. Emissions – Machine Noise Level
Source Definition Noise Level
ISO 11202: 1995 The declared emmisions level of the working machine, anytime the
machine is running/idling.
LpAeg,T =
65+4 [ dB ]
ISO 11202: 1995 The declared emmisions level of the working machine when it is
cutting a low alloy steel.
LpAeg,T =
65+4 [ dB ]
