DS-320SA
Instruction Manual - 48 -
www.doallsaws.com
11.4 HOW TO REPLACE THE CLEANING BRUSH
The right function of the cleaning brush is one of the very important factors to achieve the highest possible
blade life. Edges of teeth that aproaches the material must be clean ( without chips). That is why we ask you
to check the cleeaning brush and its position to blade teeth.
The right position of the cleaning brush towards the blade set by screws (pos.1)
1)
1 Loosen the safety screw (pos. 1)
2)
Replace the worn out brush with a new brush.
3)
Tighten the safety screw (pos. 1)
pic: 11-4
RIGHT INCORRECTLY INCORRECTLY
11.4.1 HOW TO CHANGE THE BRUSH
If the brush is worn out and it does not carry out its function, it must be changed.
1) Loose the safety screw (pos. 2)
2) Change the brush for a new one
3) Tighten the safety screw (pos. 2)
pic: 11-5
