DoAll DS-320SA - 12.5.1 EXTRA ACCESSORIES

DS-320SA
Instruction Manual - 52 -
www.doallsaws.com
12.5.1 EXTRA ACCESSORIES
pic: 12-1
CODE
OPTION
300-M2V Engine with the gear box- 2 speed
300
-
F
Motor and frequency converter for a fluent change of the circumferential speed of the blade. ST
OZM
Measuring end stop which is mounted directly to the machine, length 1m. ST
240
-
CK
Cleaning brush of blade, driven passively (driven by sawing blade). ST
-BRP Electronical regulation of the down-shift.
ST
300-DPP Automatic end stop of the upper position.
ST
300-SKZ Slide of cut pieces.
300-PUD Digital indicator of adjusted angle
OP
300-SRZ-R Vice behind the cut
300
-
SRZ
Vice behind the cut. Hydraulic clamping of the material behind the cut. OP
290-RP Manual upper vice.
