300x320 HP Hydraulical upper vice. Hydraulic upper clamping tighten the material in vertical sense by the
hydraulic cylinder.
O
300x320 HP-A Hydraulical upper vice for mounted on the main vice and on the feeding vice. Hydraulic upper
clamping tighten the material in vertical sense by the hydraulic cylinder. Set of 2 pcs.
300-RTS Regulation press of vice.
O
300
-
RTS
-
A
Regulation press of vice – set of 2 pcs for bothvices.
300-VTT Worm chip extractor for long chips (stainless-chips), includedd 1 pc of BOX-TRI.
BOX
-
PCS
Box for cutted pieces with emulsion draining to the waterproof tank. O
BOX
-
TRI
Box for the chips with emulsion draining to the waterproof tank. O
BOX
-
TAH
Tool for manipulation with BOX-PCS and BOX-TRI. O
LIGHT L1 Lighting of working space.
OP
MINI LUBE Wasteless lubricating system, instead of emulsion cooling, specially for cutting profiles and non-
ferrous metals, necessary supply of pressed air 6 Atm.
OP
300-LR-RDP Input connecting part of the roller conveyor RD - ensures angle cuts of the machine, length
1000 mm, width 390 mm, bearing capacity 200 kg/m, adjustable leg includedd in price.
O
300-LR-RDZ Output connecting part of the roller conveyor RD-ensures angle cuts of the machine, length
1000 mm, width 390 mm, bearing capacity 200 kg/m, adjustable leg includedd in price.
O
RD 1000/390 Roller conveyor. Length 1000 mm, width of cylinders 390 mm, capacity 200 kg/m, adjustable
leg includedd in price.
O
RD 2000/390 Roller conveyor. Length 2000 mm, width of cylinders 390 mm, capacity 200 kg/m, adjustable leg
includedd in price.
O
RD VR-390 Robust cylinder length 390 mm with the bearing for RD roller coneyor. The capacity of roller
table increased from 200 kg/m to 400 kg/m
O
RB 200
Side vertical fix cylinder, height 200 mm, monted on the RD tables. O
RBS 200/390
Side vertical moovable cylinder, height 200 mm, working only with RB. O
RHS 390 Horizontal cylinder , working only together with RB + RBS for bundle fixing, length of cylinder
390 mm.
O
OZ 1000 Mechanic measuring system with the meter L = 1200 mm.
O
OZ 2000
Mechanic measuring system with the meter L = 2200 mm. O
OZ 3000
Mechanic measuring system with the meter L = 3200 mm. O
OZ 4000 Mechanic measuring system with the meter L = 4200 mm.
O
OZ 5000
Mechanic measuring system with the meter L = 5200 mm. O
OZ 6000
Mechanic measuring system with the meter L = 6200 mm. O
OZD 1000
Mechanic measuring system with digital display 1 meter long. O
OZD 2000
Mechanic measuring system with digital display 2 meter long. O
OZD 3000
Mechanic measuring system with digital display 3 meter long. O
OZD 4000
Mechanic measuring system with digital display 4 meter long. O
OZD 5000
Mechanic measuring system with digital display 5 meter long. O
OZD 6000
Mechanic measuring system with digital display 6 meter long. O
OZ 0000 Second movable stop for OZ.
O
RDN Support for RD.
O
R390
Movable cylinder, adjustable height, width 390 mm, capacity 200 kg O
300x320-
QPARTS
Set of easy worn away spare parts:
* 4 pcss: hard-metal plate 235
* 4 pcss: bearing 608 2Z
* 10 pcs: cleaning brush 240-CK
O
300 - NAV Manual instruction – printed version.
O
PAL1 Packing on the palette 1,2 m x 2,0 m.
O
PAL2 Packing on the palette 2,4 m x 2,4 m.
OBAL1 Package - wooden box 1,2 m x 2,0 m.
O
OBAL2 Package - wooden box 2,4 m x 2,4 m.
OBAL
-
300
Packing in the wooden cage.
O
tab: 12-2
O – accessories, OP – accessories mounted directly in the production, ST – standard equipment
