DS-320SA
Instruction Manual - 60 -
www.doallsaws.com
2) On input is necessary to use roller table LR-RDTP. For output is necessary to use roller table LR-RDTZ.
Both those roller tables are being connected directly to machine, no need to use separate connecting parts.
pic: 12-8
WARNING: When installing roller tables, it is important to align them correctly with the horizontal level
of the saw (i.e. level determined by the tangent of the support rollers). If the routes are not in alignment, the
material will be undercut, the saw-band will not reach its maximum life and the power necessary for handling
the material will become several times higher (i.e. the life of the vice jaws and hydraulic cylinders will
decrease) and the accuracy of the material supply will fall. dramatically
NOTE: during careless handling, the bars can roll down from the roll-way.
The only safe solution is to use the RBR+RBRS side rollers.
pic: 12-9
