INSTALLATION
EPT024619 Issue 1 June 2016 6-25
OUTPUT CONNECTIONS
NPN Output Signal Connection
CAUTION: Turn off the G20i and disconnect the power before
making any wiring connections.
The printer can generate an NPN output signal from the Extended Port after
each print.
NPN Output Signal Wiring Diagram
14
Output
Signal
Extended
Port
