INSTALLATION
6-40 EPT024619 Issue 1 June 2016
Set the Print Speed
The procedures below, describe how to manually set the print speed.
If the printer is not using a shaft encoder to measure print speed, the print
speed must be manually set.
Note: It is recommended to use a shaft encoder to measure print
speed if the production line speed varies.
The minimum speed which can be set is 0.1m/min.
The maximum speed which can be set is 228m/min, but this is dependant
on the print density and print resolution settings, shown in the table below.
Using the Wireless USB Keyboard
To set the print speed using the wireless USB keyboard:
(1) From the main menu, highlight Settings.
(2) Press the Enter button.
(3) Move the cursor to highlight Speed.
(4) Press the Enter button.
(5) Type in the speed of the production line conveyor (m/min).
(6) Press the Enter button.
(7) Press ESC to return to the main menu.
Using a PC
To set the print speed using a PC:
(1) Open the Domino G20i software.
(2) Open the Printer Control menu.
(3) In the Speed text box, type the speed of the production line conveyor
(m/min).
123455
300x300 76m/min 38m/min 25m/min 19m/min 15m/min
300x150 152m/min 76m/min 50m/min 38m/min 30m/min
300x100 228m/min 152m/min 101m/min 76m/min 60m/min
Resolution
Density
