DESCRIPTION
2-12 EPT024619 Issue 1 June 2016
Settings Menu
The Settings menu contains the following items:
Speed Setup an encoder to measure the production line
speed.
Or, enter a manual value for the production line speed.
Resolution Set the print resolution.
Density Set the print density.
Delay Set the distance between when the print trigger is
activated and when a message will be printed.
And, set the distance between printed messages.
Cartridge Manually enter the quantity of ink in the ink cartridge,
and display the ink type.
Update Logo Update a logo or image from a USB stick to the
printer’s internal memory.
String Create and update strings of text which can be inserted
into messages.
Purge Purge the print head at regular intervals to prevent print
head nozzles from blocking during periods of inactivity.
Print Side Select which row of nozzles will be used for printing, or
automatically switch nozzle rows.
Sensor Select whether the internal, or an external product
sensor is used to trigger message printing.
Directions Set the print direction.
Print Mode Set the print mode / trigger.
Unit Select the unit of measurement.
(mm or inch)
Bluetooth Enable, disable and setup the Bluetooth connection to
control the G20i from an Android device.
Update Font Update the font type.
Rollover Enable or disable a different time value depending on
the production shift schedule.
(The default time value is 00:00)
System clock Set the time and date for the system clock.
Rotate Select screen modes.
(Auto rotate or Lock rotate)
