DESCRIPTION
2-6
EPT024619 Issue 1 June 2016
Print
er Connections
A
12V DC power supply input.
B
Seria
l connection for an e
xternal pr
oduct sensor
,
shaft encoder
,
alarm beacon, etc.
C
USB-B port for PC connection.
D
USB flash port for updating firmware, fonts and logos.
E
USB p
ort for the wireless USB keyboard receiver
.
Pri
n
te
r C
on
ne
c
ti
o
ns
A
B
C
D
E
19
21
