3.3.39 Cylinder head cover
Attach a new gasket on the cylinder head cover.
Assemble the cylinder head cover to the cylinder head
by tightening the cap bolts for fixing the cylinder head
cover.
Assemble the breather and breather hose.
Fit the oil filler cap on the cylinder head cover.
3.3.40 Cooling fan
Install the flange to the water pump pulley, then
assemble the cooling fan to the pulley by tightening the
fixing bolts.
3.3.41 Belt
Install the V-belt on the crank pulley,alternator pulley
and water pump pulley.
Adjust the V-belt tension using the tension adjusting
support.
SPC000006 5ton Diesel Engine
Page 86
