Install intermediate plate and 2nd gasket.
Assemble channel plate and fasten it by means of
socket head screws.
Torque limit (M8/8.8) 23 Km
NOTE ;
Pay attention to a correct position of the ball seat
valves !
Pay attention to the position of the various screws,
see corresponding Spare Parts List !
Assemble 1st gasket.
NOTE ;
Pay attention to the different gaskets, see Figure 28
and 29 !
Install intermediate plate and 2nd gasket.
SPC000007 Transmission and Torque Converter
Page 22
