Squeeze in rectangular ring (Arrow 1) and engage
it.
Insert O-Ring (Arrow 2) in the recess of the turbine
wheel hub and grease it.
Thread up pro-assembled turbine wheel until the
inner plates have been received.
Heat stator and insert free wheel outer ring until
contact s obtained.
Fix free wheel outer ring by means of snap ring.
Transmission and Torque Converter SPC000007
Page 81
