Install rotor set, fix cover provisionally by means of
hex. head screws and insert the straight pins (with
the tapped hole showing upwards) until contact is
obtained.
Fix the straight pins axially by means of caulkings
(2x) and tighten hex. head screws finally.
Remove converter relief valve (ball and spring).
Squeeze out circlip.
(S) Set of external 5870 900 016
snap ring pliers
Press drive shaft in direction of Arrow until the spur
gear is released.
Transmission and Torque Converter SPC000007
Page 89
