Install screw plug.
Mount closing cover until it is flush.
NOTE ;
Wet sealing surface with Loctite (Type-No.270).
3.2.10 Converter charge pump and
control pressure pump
Squeeze rectangular rings into the annular grooves
of the drive shaft and engage them.
Insert the two roll pins (1,5x5 and 2,5x5 mm)
flush-mounted in the bore (Arrow).
Press bearing outer race firmly against shoulder
Transmission and Torque Converter SPC000007
Page 151
