Mount oil line (Arrow).
NOTE ;
Use new sealing rings !
3.2.12 Coaxial power take-off
(controllable)
Install snap rings and needle bush.
NOTE :
The needle bush is marked on one end face.
At the pressing in, the marking must be facing the
drift ( S ) !
( S ) Drift 5870 506 060
Squeeze the two snap rings into the annular groove
of the housing.
Assemble roller cage and collar shim, and fix them
by means of circlip.
NOTE ;
Pay attention to the installation position of the roller
cage (annular groove)!
Transmission and Torque Converter SPC000007
Page 159
