Insert output gear in the housing and displace it in
direction of Arrow, to make the later reassembly of
the planetary carrier possible.
Introduce planetary carrier with the long hub side
showing downwards, into the internal gear.
Lay supporting plate upon the output gear (Figure
61) and fix it by uniform tightening of the socket
head screws (Figure 62).
Torque limit (Ml0/10.9) 68 Nm
NOTE:
Secure socket head screws with Loctite (Type No.
241)!
SPC000007 Transmission and Torque Converter
Page 204
Figure 59
Figure 60
Figure 61
Figure 62
