Press ball bearing against shoulder until contact is
obtained.
Fix ball bearing by means of circlip.
Install shaft seal with the sealing lip facing the oil
chamber (downwards).
NOTE :
By appliation of the prescribed driver, the exact
installation position is obtained !
If the outer diameter of the shaft seal is rubberized,
wet the sealing surface with spirit !
If not, use a sealing compound !
Crease scaling lip !
( S ) Driver 5870 055 05«
( S ) Handle 5870 260 002
Support the bearing inner race of the ball bearing
and press cover against shoulder until contact is
obtained.
SPC000007 Transmission and Torque Converter
Page 220
