7. ① Pull out driving gear & driven gear keeping
gears as straight as possible.
② Remove other pressure plate on rear side with
same way for front side
8. ①Remove the pressure plate with prearranged
parts, O-ring & back up ring from the working
section and examine it carefully.
②Pull out driving gear & driven gear keeping
gears as straight as possible.
9. ①Remove rear cover and other pressure plate at
rear side with same way for front side.
Steer Pump SPC000013
Page 9
