10. ①Take out two square rings from the body.
Assembling steps
Assembling of front cover assembly
1. ① Smear clean grease on pressure plate groove
②Locate O-ring into the grove on the aluminum
pressure plate.
③Locate back-up ring upon the O-ring.
2. ① repeat same procedure.
SPC000013 Steer Pump
Page 10
